| Item |
PS60A-24B Adapter Set |
| Used With | FVP10/TSP100PUSB/TSP650/TSP700II/
TSP800II/TSP828L/TSP1000/TUP500/
TUP900/SP298/HSP7000 |
| Item |
PS8340A Adapter Set |
| Used With |
DP8340 |
Wall Bracket
| Item |
WB-T700 |
WB-T800 |
| Used With |
TSP700II |
TSP700II |
Vertical Stand
| Item |
VS-T650 |
VS-T700 |
VS-T800 |
| Used With | TSP100/100ECO
TSP650 |
TSP700II |
TSP800II |
Mount kit
| Item |
MK-F10 |
| Used With | FVP10 |
SF03BR
| Item |
SF03BR |
| Color |
Black and Red |
| Life |
Red: 0.4million characters
Black: 0.8million characters |
| Dimensions |
- |
| Used With | DP8340 |
RC200BR
| Item |
RC200BR |
| Color |
Black and Red |
| Life |
Red: 0.3million characters
Black: 0.6million characters |
| Dimensions |
114.4×65×28mm |
| Used With | MP200 |
RC200B
| Item |
RC200B |
| Color |
Black and Red |
| Life |
1.5 million characters |
| Dimensions |
114.4×65×28mm |
| Used With | MP200, MP292, MP500, SP298, SP500 |
RC300B
| Item |
RC300B |
| Color |
Black |
| Life |
2.6 million characters |
| Dimensions |
116.4×66.5×28mm |
| Used With | MP300, SP320 |
RC330B
| Item |
RC330B |
| Color |
Black |
| Life |
2.6 million characters |
| Dimensions |
116.4×66.5×28mm |
| Used With | MP330 |
RC100B
| Item |
RC100B |
| Color |
Black |
| Life |
0.8 million characters |
| Dimensions |
103×66.8×28mm |
| Used With | MP400 |
RC700B
| Item |
RC700B |
| Color |
Black |
| Life |
3.0million characters |
| Dimensions |
139.1×67.5×28mm |
| Used With | SP700 |
RC700BR
| Item |
RC700BR |
| Color |
Black and Red |
| Life |
Red: 0.75million characters
Black: 1.5million characters |
| Dimensions |
139.1×67.5×28mm |
| Used With | SP700 |
RC-7KB
| Item |
RC-7KB |
| Color |
Black |
| Life |
4 million |
| Dimensions |
148.4×66.4×28mm |
| Used With | HSP7000 |
| Item |
PW349 |
| Paper width |
2.25"(57mm), 3"(76mm), 3.25"(82.5mm) |
| Roll diameter |
1ply-max.2.25", 2ply-max.3" |
| Thickness |
1ply-max.0.003"(0.07mm) to 0.003"(0.08mm)
2ply-max.0.006"(0.14mm) |
| Motor terminal voltage |
DC24V ± 10% |
| Current |
Max.150mA in operation, Av 70mA |
| Power consumption |
Av. 1.7W |
| Operating conditions |
0ºC to 50ºC, 10% to 90% RH (w/o condensation) |
| Storage conditions |
-20ºC to 7ºC, 5% to 95% RH (w/o condensation) |
| Reliability |
5 million lines |
| Dimensions |
118(W) x 74.5(D) x 90(H)mm |
| Weight |
Approx. 225g |
| Item |
BU01-24-A |
| Used With |
TSP100*/TSP100ECO
TSP650/TSP700II/SP700
*Except for TSP100PUSB |
| Item |
DP8901 |
DP8302
DP8304A |
| Number of pins |
9 |
| Supply voltage |
24V |
12V |
| Current |
0.9A |
1.8A |
| Pulse width |
340 sec |
460sec |
| Reliability |
200 million characters |
70 million characters |
